Generator Set
Powered by Mahindra Powerol engines PERFECT offers you a complete range of Silent Diesel Generators.
Mahindra 82.5 KVA DG Set
Product Details:
| Voltage | Mahindra |
| Power | 82.5 kVA |
| Phase | Three Phase |
| Dimensions | 3200x1300x2290 mm |
| Fuel Tank Capacity | 200 L |
| No of Cylinder | 4 |
| Rated Speed | 1500 RPM |
| Rated Current | 115 A |
| Weight | 1700 kg |
Backed by massive industry proficiency, we are involved in presenting to our customers' world class Mahindra 82.5 KVA DG Set.
Callback
Mahindra 30 KVA DG Set
Product Details:
| Minimum Order Quantity | 1 Piece |
| No. Of Cylinder | 3 |
| Cooling System | Water |
| Phase | Single Phase |
| Side Lifting DG Set Dimension | 250x1030x1376 mm |
| Fuel Tank Capacity | 130 L |
| Power Rating | 30 kVA |
| Rated Speed | 1500 RPM |
| Rated Current | 130.4 A |
| Weight | 950 kg |
| Centre Lifting DG Set Dimension | 2500x1030x1390 mm |
| Brand | Mahindra |
Backed by massive industry proficiency, we are involved in presenting to our customers' world class Mahindra 30 KVA DG Set.
Callback
7.5 kVA Mahindra Powerol Diesel Generator, 3 Phase
Product Details:
| Minimum Order Quantity | 1 Piece |
| Power (kVA) | 7.5 kVA |
| Genset Brand | Mahindra Powerol |
| Phase | 3 Phase |
| Voltage | 240 V |
| Fuel Tank Capacity | 90 Ltr |
| Dry Weight (Kg) | 700 |
| Frequency | 50 Hz |
| Cooling System | Water cooling |
| Sound Level | 75 dB |
| Dimension | 2215 X 1050 X 1336 mm |
Mahindra mPower Engine:
· Higher block loading capacity
· Linear fuel consumption
· Low ownership cost
· Mechanical/Common rail fuel injection system
· Modular cylinder head for easy serviceability
Genset Controller:
Deep Sea Electronics make premium controller that delivers accurate metering, best-in-class protection for optimum genset performance. With Genset controller, the genset is always protected against breakdowns from electrical or mechanical flaws and thereby ensures maximum uptime.
Key Features:
· Compatible with Auto Mains Failure facility
· 500 event log memory storage
· Comes with RS485 port for modbus communication as standard scope
· Activation time delay for oil pressure. coolant temperature, voltage and frequency faults
· Routine maintenance & service alerts
· 5 configurable inputs
· Sleep mode
· Remote start & stop facility
Genset Monitoring (Key Parameters):
· Generator/load power (kW, kVA. kVAr. pfj, generator/load current, battery voltage
· RPM, running hours, oil pressure, engine temperature and fuel level
Genset Protection (Key Parameters):
· High engine temperature, low oil pressure, engine over/under speed
· Over current. over/under voltage. Charging alternator low voltage
Alternator:
· Brushless type, screen protected, revolving field, self-excited alternator conforming to IS/IEC 60034-1
· 3 Phase reconnect type winding with 12 terminals brought out for connection
· Superior winding for harmonic reduction
· Epoxy coating for consistent performance in all weather conditions
· Better transient response capability
Acoustic Enclosure:
· Aesthetically designed at Mahindra Research Valley
· Designed by using latest technology aids like Computer aided Engineering (CAE). Noise-Vibration Harshness Engineering (NVH) and Computational Fluid Dynamics Engineering (CFO) which resulted in lowest foot print & lowest noise levels
Optional Accessories:
PMS alternator, RTD/BTD Space Heater, Coolant/ Oil heater. Heavy duty air cleaner, synchronization. For more details kindly contact our authorized representative
Callback
15 kVA Mahindra Powerol Diesel Generator, 3 Phase
Product Details:
| Power (kVA) | 15 kVA |
| Genset Brand | Mahindra Powerol |
| Phase | 3 Phase |
| Fuel Tank Capacity | 55 Ltr |
| Dry Weight (Kg) | 650 |
| Frequency | 50 Hz |
Mahindra mPower Engine:
· Higher block loading capacity
· Linear fuel consumption
· Low ownership cost
· Mechanical/Common rail fuel injection system
· Modular cylinder head for easy serviceability
Genset Controller:
Deep Sea Electronics make premium controller that delivers accurate metering, best-in-class protection for optimum genset performance. With Genset controller, the genset is always protected against breakdowns from electrical or mechanical flaws and thereby ensures maximum uptime.
Key Features:
· Compatible with Auto Mains Failure facility
· 500 event log memory storage
· Comes with RS485 port for modbus communication as standard scope
· Activation time delay for oil pressure. coolant temperature, voltage and frequency faults
· Routine maintenance & service alerts
· 5 configurable inputs
· Sleep mode
· Remote start & stop facility
Genset Monitoring (Key Parameters):
· Generator/load power (kW, kVA. kVAr. pfj, generator/load current, battery voltage
· RPM, running hours, oil pressure, engine temperature and fuel level
Genset Protection (Key Parameters):
· High engine temperature, low oil pressure, engine over/under speed
· Over current. over/under voltage. Charging alternator low voltage
Alternator:
· Brushless type, screen protected, revolving field, self-excited alternator conforming to IS/IEC 60034-1
· 3 Phase reconnect type winding with 12 terminals brought out for connection
· Superior winding for harmonic reduction
· Epoxy coating for consistent performance in all weather conditions
· Better transient response capability
Acoustic Enclosure:
· Aesthetically designed at Mahindra Research Valley
· Designed by using latest technology aids like Computer aided Engineering (CAE). Noise-Vibration Harshness Engineering (NVH) and Computational Fluid Dynamics Engineering (CFO) which resulted in lowest foot print & lowest noise levels
Optional Accessories:
PMS alternator, RTD/BTD Space Heater, Coolant/ Oil heater. Heavy duty air cleaner, synchronization. For more details kindly contact our authorized representative
Callback
Silent Dg Set
Product Details:
| Power | Silent D.G.Sets |
| Cooling System | Water Cooling, Liquid Cooling |
| Fuel Type | Diesel |
| Voltage | 415 |
| Model Name/Number | Silent D.G.Set |
| Number of Cylinder | 4 |
| Rated Speed | 1500 RPM |
| Fuel Tank Capacity | 230 L |
| Weight | 1350 kg |
| Centre Lifting DG Set Dimension | 2800x1150x1640 mm |
| Brand | Mahindra |
| Phase | Three Phase |
Backed by massive industry proficiency, we are involved in presenting to our customers' world class Silent Dg Set.
Callback
Mahindra 160 Kva Dg Sets
Product Details:
| Minimum Order Quantity | 1 Piece |
| Cooling System | Water Cooling |
| Brand | Mahindra |
| Number of Cylinder | 6 |
| Rated Speed | 1500 RPM |
| Fuel Tank Capacity | 250 L |
| Weight | 2350 kg |
| Power | 160 |
| Rated Current | 222.6 A |
| Centre Lifting DG Set Dimension | 3750x1300x1700 mm |
With enriched industrial acquaintance, we are providing a varied series of Mahindra 160 KVA DG Sets.
Callback
Mahindra 25 KVA DG Sets
Product Details:
| Minimum Order Quantity | 1 Piece |
| Cooling System | Water Cooling |
| Brand | Mahindra |
| Power | 25 kVA |
| Number of Cylinder | 3 |
| Rated Speed | 1500 RPM |
| Fuel Tank Capacity | 130 L |
| Phase | Three Phase |
| Weight | 820 kg |
| Side Lifting DG Set Dimension | 2500x1030x1376 mm |
| Centre Lifting DG Set Dimension | 2500x1030x1390 mm |
Backed by massive industry proficiency, we are involved in presenting to our customers' world class Mahindra 25 KVA DG Set.
Callback
Mahindra 40 kVA DG Sets
Product Details:
| Brand | Mahindra |
| Number of Cylinder | 3-4 |
| Weight | 950 kg |
| Fuel Tank Capacity | 130 L |
| Rated Speed | 1500 RPM |
| Cooling System | Water Cooling |
| Power | 40 kVA |
| Rated Current | 130.4-173.9 A |
| Dimensions | 2500x1030x1376 mm |
Backed by massive industry proficiency, we are involved in presenting to our customers' world class Mahindra 40 KVA DG Set.
Callback
250 Kva Mahindra Powerol Dg Set
Product Details:
| Minimum Order Quantity | 1 Piece |
| No. Of Cylinder | 6 |
| Fuel type | Diesel |
| Voltage | 415 V |
| Frequency | 50 Hz |
| Cooling System | Water |
| Mccb Rating | 400 A |
| Power | 250 kVA |
| Current | 1500 RPM |
| Brand | Mahindra |
| Fuel Tank Capacity | 575 Lts |
Backed by massive industry proficiency, we are involved in presenting to our customers' world class 250 KVA Mahindra Powerol D.G.Set.
Callback
Additional Information:
- Pay Mode Terms: T/T (Bank Transfer)
- Delivery Time: 2 to 4 weeks
Mahindra 320 KVA Diesel Generator
Product Details:
| Engine Make | Mahindra |
| Rating | 320 kva |
| Model Name/Number | M POWER |
| Voltage | 415 |
| Fuel Type | Diesel |
| Power | 320 kva |
To meet the varying desires of our clients, we are engrossed in providing highly reliable Mahindra Powerol 320 kva Generator
Callback
Mahindra 20 Kva Dg Sets
Product Details:
| Cooling System | Water Cooling |
| Brand | Mahindra |
| Rated Speed | 1500 RPM |
With enriched industrial acquaintance, we are providing a varied series of Mahindra 20 KVA DG Sets.
Callback
Kirloskar Generator 200kva
Product Details:
| AMC | Available |
| On-site Service | Available |
| Country of Origin | Made in India |
| Deal In | New |
Kirloskar 200 kva
Callback
5 kVA Mahindra Powerol Diesel Generator, 1 Phase
Product Details:
| Minimum Order Quantity | 1 Piece |
| Power (kVA) | 5 kVA |
| Genset Brand | Mahindra Powerol |
| Phase | Single Phase |
| Fuel Tank Capacity | 15 Ltr |
| Dry Weight (Kg) | 210 |
| Frequency | 50 Hz |
| Dimensions | 1050 x 700 x 745 mm |
Mahindra mPower Engine:
· Higher block loading capacity
· Linear fuel consumption
· Low ownership cost
· Mechanical/Common rail fuel injection system
· Modular cylinder head for easy serviceability
Genset Controller:
Deep Sea Electronics make premium controller that delivers accurate metering, best-in-class protection for optimum genset performance. With Genset controller, the genset is always protected against breakdowns from electrical or mechanical flaws and thereby ensures maximum uptime.
Key Features:
· Compatible with Auto Mains Failure facility
· 500 event log memory storage
· Comes with RS485 port for modbus communication as standard scope
· Activation time delay for oil pressure. coolant temperature, voltage and frequency faults
· Routine maintenance & service alerts
· 5 configurable inputs
· Sleep mode
· Remote start & stop facility
Genset Monitoring (Key Parameters):
· Generator/load power (kW, kVA. kVAr. pfj, generator/load current, battery voltage
· RPM, running hours, oil pressure, engine temperature and fuel level
Genset Protection (Key Parameters):
· High engine temperature, low oil pressure, engine over/under speed
· Over current. over/under voltage. Charging alternator low voltage
Alternator:
· Brushless type, screen protected, revolving field, self-excited alternator conforming to IS/IEC 60034-1
· 3 Phase reconnect type winding with 12 terminals brought out for connection
· Superior winding for harmonic reduction
· Epoxy coating for consistent performance in all weather conditions
· Better transient response capability
Acoustic Enclosure:
· Aesthetically designed at Mahindra Research Valley
· Designed by using latest technology aids like Computer aided Engineering (CAE). Noise-Vibration Harshness Engineering (NVH) and Computational Fluid Dynamics Engineering (CFO) which resulted in lowest foot print & lowest noise levels
Optional Accessories:
PMS alternator, RTD/BTD Space Heater, Coolant/ Oil heater. Heavy duty air cleaner, synchronization. For more details kindly contact our authorized representative
Callback
